Bathroom Extractor Fan - Super Powerful Motor with Ball Bearing - 100mm
- Brand: CNCEST
- Product Code: HG-ZMWHY-1305
- Availability: In Stock

Widely used: The air exhaust fan is widely used in homes, offices, warehouses, restaurants, bars, shops, shopping malls, greenhouses and other places where a lot of ventilation is required. air.
Large Airflow - It is designed with premium sleeve motor, quiet and over 3 years lifespan
Overheat Protection - The motor comes with low operating temperature and low heat generation, the built-in temperature protection device, the contact point is separated when the motor overheats, which acts as protection against overheating. power outages. Double protection for added safety.
DIY your HVAC system – You can supply fresh air with one or more fans for DIY air circulation systems.
Easy to install - This model with an extra powerful motor with ball bearing is also suitable for vertical mounting. The fan is compatible with our air channels of the same diameter.
The plastic fan is ideal for extracting air in residential and commercial spaces, such as offices, bathrooms, shops, kitchens, toilets, etc.
This model equipped with an extra powerful motor with ball bearing is also suitable for vertical mounting.
The fan is compatible with our air channels of the same diameter.
The tubular fan housing is made of premium ABS plastic.
Technical characteristics :
1. 100mm round tubular fan.
Product Name: Tubular Pressure Fan
Sound level: 34 dB.
Air flow: 130 m3/h.
Air outlet: 100 mm.
Speed: 2400 rpm.
Tension nominale : 220 V.
Rated power: 12W.
Rated frequency: 50 Hz.
Control method: mechanical control.
Exterior material: ABS.
ABS material/oil bearing motor.
2. 125mm round tubular fan.
Product Name: Tubular Pressure Fan
Sound level: 34 dB.
Air flow: 240 m3/h.
Air outlet: 125 mm.
Speed: 2200 rpm.
Tension nominale : 220 V.
Rated power: 16W.
Rated frequency: 50 Hz.
Control method: mechanical control.
Exterior material: ABS.
ABS material/oil bearing motor.
3. Square wall fan Ø 100 mm.
With non-return valve.
Operating temperature: -20/+60°C.
Horizontal installation (vertical installation is not recommended, the check valve does not open).
Polypropylene and ABS plastic housing.
IPX4 protection rating - Protection against solid bodies.
Insulation class B - Protection against splashing water.
Technical characteristics :
- Air flow: max. : 100 m³/h
- Power: 19 W
- Supply voltage: 230 V at 50/60 Hz.
- Sound pressure level: 39 dB (A)/3 m.
- Flange diameter: Ø 100 mm.
