Hydraulic Crimping Pliers Manual Hydraulic Crimping Pliers Fast and Efficient Copper Pipe Crimping Pliers Set for Personal Workshops Black
- Brand: CNCEST
- Product Code: JZONDT-003000
- Availability: In Stock

Specifications
Color | Black | Model | CW-1632 |
Grip Type | Ergonomic | Material | 41Cr4, Rubber |
Process | Polishing, Electroplating, Oxidation, Plastic Spraying | Max. Pressure | 8-10T/80-100KN |
Applicable Pipe | Copper Pipe (Not Included) | Die Specifications | VAU15, VAU20, VAU25 |
Applicable Pipe Outer Diameter | 12mm/0.47in, 19mm/0.75in, 25mm/0.98in | Stroke | 15mm/0.59in |
Handle Length | 25cm/9.84in | Head Width | 9cm/3.54in |
Product Size (L*W) | 38*11-26cm/14.96*4.33-10.24in | Package Size | 44*19*9cm/17*7*3.5in |
Gross Weight | 4.6kg/10lbs |
Product Tips


Notes
1.Please read the operating manual completely before use. And pay particular attention to the safety instructions included.
2.It is strictly prohibited to start crimping without installing the die.
3.Please observe if there is enough space for the pliers to enter during use to avoid situations where the pliers cannot enter or get stuck.
4.After use, please turn the oil return valve to release pressure.

How to Use
1. Turn off the oil return knob and insert the die
2. Insert the pipe and adjust the oil return knob to "ON".
3. Press the handle repeatedly.
4. Adjust the knob to "OFF" and remove the pipe.
